9-1415389-1 - TE Connectivity
Power Relay, Spdt, 5A, 250V, Pcb Rohs Compliant: Yes |Schrack Te Connectivity 9-1415389-1..
Technical Details
| Ambient Temperature Range High | 85°C |
| China RoHS | Compliant |
| Coil Current | 100mA |
| Coil Power | 220mW |
| Coil Resistance | 22Ω |
| Coil Voltage (DC) | 1.65V |
| Contact Current Rating | 5A |
| Contact Material | Silver |
| Contact Voltage Rating (AC) | 400V |
| Current Rating | 5A |
| Depth | 10mm |
| Dropout Voltage | 1.6V |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 100kcycles |
| ELV | Compliant |
| Height | 10mm |
| Insulation Resistance | 10TΩ |
| Introduction Date | 2019-08-24 |
| Length | 20mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Current Rating | 5A |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (AC) | 400V |
| Min Operating Temperature | -40°C |
| Mount | PCB, Through Hole |
| Number of Contacts | 1 |
| Number of Pins | 5 |
| Packaging | Carton |
| Radiation Hardening | No |
| Ratings | IP54 |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Sealable | RT2 |
| Switching Capacity | 1.25kW |
| Termination | PCB |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 400V |
| Weight | 5g |
| Width | 10mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
