9-1440003-3 - TE Connectivity
Power/Signal Relay, 1 Form C, Spdt, Momentary, 0.033A (Coil), 12Vdc (Coil), 400Mw (Coil), 5A
Technical Details
| Ambient Temperature Range High | 85°C |
| China RoHS | Compliant |
| Coil Current | 33mA |
| Coil Power | 400mW |
| Coil Resistance | 360Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 8.4V |
| Contact Current Rating | 3A |
| Contact Material | Silver, Tin |
| Contact Voltage Rating (AC) | 277V |
| Country of Origin | Mainland China |
| Current Rating | 5A |
| Depth | 10mm |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 100kcycles |
| ELV | Compliant |
| Height | 15.2mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.41.00.20 |
| Introduction Date | 2006-12-27 |
| Lead Free | Lead Free |
| Length | 20mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Current Rating | 3A |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (AC) | 277V |
| Max Voltage Rating (DC) | 30V |
| Min Operating Temperature | -40°C |
| Mount | Through Hole |
| Number of Contacts | 1 |
| Number of Pins | 5 |
| Number of Terminals | 5 |
| Operate Time | 10ms |
| Power Rating | 400mW |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Relay Type | General Purpose |
| Release Time | 5ms |
| Response Time | 10ms |
| RoHS | Compliant |
| Sealable | EPOXY TERMINAL SEALED |
| Termination | PC Pin, PCB |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 277V |
| Voltage Rating (DC) | 30V |
| Weight | 7g |
| Width | 10mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
