KRPA-11DG-125 - TE Connectivity
Electromechanical Relay 125VDC 10A DPDT(35.71x35.71)mm Socket General Purpose Relay
Technical Details
| Ambient Temperature Range High | 70°C |
| Approvals | CSA, UL |
| Case/Package | 125 |
| China RoHS | Non-Compliant |
| Coil Current | 9.6mA |
| Coil Power | 1.2W |
| Coil Resistance | 120Ω |
| Coil Type | Non-Latching |
| Coil Voltage (AC) | 125V |
| Coil Voltage (DC) | 12V |
| Contact Current Rating | 10A |
| Contact Material | Cadmium, Silver |
| Contact Voltage Rating (AC) | 240V |
| Current Rating | 10A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 100kcycles |
| ELV | Non-Compliant |
| Height | 50.8mm |
| Insulation Resistance | 1GΩ |
| Introduction Date | 2010-09-26 |
| Lead Free | Lead Free |
| Length | 35.7mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Current Rating | 10A |
| Max Operating Temperature | 70°C |
| Max Voltage Rating (AC) | 240V |
| Max Voltage Rating (DC) | 28V |
| Min Operating Temperature | -45°C |
| Mount | Socket |
| Number of Contacts | 2 |
| Number of Pins | 8 |
| Packaging | Bulk |
| Power Consumption | 1.2W |
| REACH SVHC | No |
| Relay Type | General Purpose |
| RoHS | Non-Compliant |
| Sealable | RT1 |
| Switching Current | 300mA |
| Termination | Plug |
| Throw Configuration | DPDT |
| Voltage Rating (AC) | 240V |
| Weight | 85g |
| Width | 35.687mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
