ORWH-SH-112DM1F000 - TE Connectivity
10A 277VAC 1 Pole 1 form A PCB Mount General Purpose Industrial Relay
Technical Details
| Ambient Temperature Range High | 70°C |
| China RoHS | Compliant |
| Coil Current | 30mA |
| Coil Power | 360mW |
| Coil Resistance | 400Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 8.4V |
| Contact Current Rating | 10A |
| Contact Voltage Rating (AC) | 277V |
| Current Rating | 10A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 15.8mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.41.00.20 |
| Introduction Date | 2010-09-24 |
| Length | 19mm |
| Lifecycle Status | Obsolete |
| Max Current Rating | 10A |
| Max Operating Temperature | 70°C |
| Max Voltage Rating (DC) | 28V |
| Min Operating Temperature | -30°C |
| Number of Contacts | 1 |
| Number of Terminals | 5 |
| REACH SVHC | Yes |
| Release Time | 5ms |
| Response Time | 10ms |
| RoHS | Compliant |
| Sealable | RT3 |
| Switching Current | 10A |
| Throw Configuration | SPDT, SPST |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
