V23201C1001A502 - TE Connectivity
Electromechanical Relay, SPST, Latched, 40A (Contact), 12VDC (Contact), Random, DC Output
Technical Details
| Ambient Temperature Range High | 105°C |
| China RoHS | Compliant |
| Coil Power | 818mW |
| Coil Resistance | 176Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 6.9V |
| Contact Material | Silver, Tin |
| Current Rating | 40A |
| Depth | 16mm |
| Electrical Life | 100kcycles |
| Height | 15.9mm |
| Length | 18.3mm |
| Lifecycle Status | Production |
| Max Current Rating | 40A |
| Max Operating Temperature | 105°C |
| Max Voltage Rating (DC) | 12V |
| Min Operating Temperature | -40°C |
| Mount | PCB |
| Number of Contacts | 1 |
| Number of Terminals | 6 |
| REACH SVHC | Yes |
| Release Time | 1.5ms |
| Response Time | 3ms |
| RoHS | Compliant |
| Switching Current | 200A |
| Termination | Through Hole |
| Throw Configuration | SPST |
| Voltage Rating (DC) | 12V |
| Width | 18.3mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
