| Body Material | Glass |
| Case/Package | DO-35-2 |
| China RoHS | Non-Compliant |
| Contact Plating | Silver, Tin |
| Element Configuration | Single |
| ESD Protection | No |
| Forward Voltage | 1.1V |
| Height | 2mm |
| Impedance | 5Ω |
| Lead Free | Lead Free |
| Length | 4mm |
| Lifecycle Status | Obsolete |
| Max Operating Temperature | 175°C |
| Max Power Dissipation | 500mW |
| Max Reverse Leakage Current | 3µA |
| Min Operating Temperature | -65°C |
| Mount | Through Hole |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Peak Reverse Current | 3µA |
| Polarity | Unidirectional |
| Power Dissipation | 500mW |
| Power Rating | 500mW |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Reference Voltage | 6.8V |
| Reverse Standoff Voltage | 5V |
| RoHS | Compliant |
| Termination | Axial |
| Test Current | 20mA |
| Tolerance | 5% |
| Voltage Rating (DC) | 6.8V |
| Voltage Tolerance | 5% |
| Weight | 130.010913mg |
| Width | 2mm |
| Working Voltage | 6.8V |
| Zener Current | 20mA |
| Zener Voltage | 6.8V |
onsemi
|
Production
|
Rectron
|
Production
|
Diodes Inc.
|
Obsolete
|
Taiwan Semiconductor
|
Production
|
Fairchild Semiconductor
|
Obsolete
|
