| Breakdown Voltage | 3.5V |
| Capacitance | 2.5pF |
| Clamping Voltage | 21.8V |
| Country of Origin | Mainland China |
| Direction | Bidirectional |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 1mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2013-07-18 |
| Lead Free | Lead Free |
| Leakage Current | 100nA |
| Length | 2.7mm |
| Lifecycle Status | Production |
| Max Operating Temperature | 125°C |
| Max Power Dissipation | 750W |
| Max Surge Current | 30A |
| Min Breakdown Voltage | 3.5V |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Bidirectional Channels | 1 |
| Number of Channels | 1 |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Operating Supply Voltage | 3.3V |
| Packaging | Cut Tape |
| Peak Pulse Current | 30A |
| Peak Pulse Power | 750W |
| Polarity | Bidirectional |
| Power Line Protection | No |
| REACH SVHC | Yes |
| Reverse Standoff Voltage | 3.3V |
| RoHS | Compliant |
| Schedule B | 8536300000, 8536300000|8536300000|8536300000|8536300000|8536300000 |
| Termination | SMD/SMT |
| Width | 1.4mm |
| Working Voltage | 3.3V |
