2N5428

Motorola
2N5428
Obsolete
Power Bipolar Transistor, 7A I(C), 80V V(BR)CEO, 1-Element, NPN, Silicon, TO-213AA, Metal, 2 Pin

Body Material	Metal
Collector Emitter Saturation Voltage	1.2V
Collector Emitter Voltage (VCEO)	80V
Country of Origin	USA
Export Control Classification Number (ECCN) Code	EAR99
hFE Min	40
Harmonized Tariff Schedule (HTS) Code	8541.29.00.95
Introduction Date	1983-08-26
Lifecycle Status	Obsolete
Max Collector Current	7A
Max Operating Temperature	175°C
Max Power Dissipation	40W
Number of Elements	1
Number of Terminals	2
Power Dissipation	40W
RoHS	Non-Compliant
Transition Frequency	30MHz
