| Breakdown Voltage | 6.8V |
| Capacitance | 4nF |
| Case/Package | DO-15 |
| China RoHS | Non-Compliant |
| Clamping Voltage | 13.4V |
| Composition | Zener |
| Diameter | 3.53mm |
| Direction | Unidirectional |
| Element Configuration | Single |
| Lead Free | Lead Free |
| Leakage Current | 10mA |
| Length | 6.75mm |
| Lifecycle Status | Obsolete |
| Max Breakdown Voltage | 7.14V |
| Max Operating Temperature | 175°C |
| Max Power Dissipation | 5W |
| Max Reverse Leakage Current | 10mA |
| Max Surge Current | 10mA |
| Min Breakdown Voltage | 6.45V |
| Min Operating Temperature | -55°C |
| Mount | Through Hole |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Number of Unidirectional Channels | 1 |
| Operating Supply Voltage | 5.8V |
| Peak Pulse Current | 298A |
| Peak Pulse Power | 600W |
| Peak Reverse Current | 10µA |
| Polarity | Unidirectional |
| Power Dissipation | 600W |
| Power Line Protection | No |
| Power Rating | 600W |
| Radiation Hardening | No |
| REACH SVHC | No |
| Reverse Breakdown Voltage | 6.45V |
| Reverse Standoff Voltage | 5.8V |
| RoHS | Compliant |
| Schedule B | 8541100080, 8541100080|8541100080|8541100080|8541100080|8541100080 |
| Test Current | 10mA |
| Voltage Rating (DC) | 6.8V |
Diodes Inc.
|
Production
|
Diodes Inc.
|
Obsolete
|
Diodes Inc.
|
Obsolete
|
Diotec
|
Production
|
STMicroelectronics
|
Obsolete
|
