Technical Details
| Capacitance | 22pF |
| Case Code (Imperial) | 0805 |
| Case Code (Metric) | 2012 |
| Case/Package | 0805 |
| Construction | Flat |
| Depth | 1.25mm |
| Dielectric | C0G |
| Dissipation Factor | 10% |
| Height | 0.94mm |
| Length | 2.01mm |
| Material | Ceramic |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Package Quantity | 4000 |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Temperature Coefficient | 30ppm/°C |
| Termination | SMD/SMT |
| Thickness | 0.037inch |
| Tolerance | 1% |
| Voltage Rating | 100V |
| Voltage Rating (DC) | 100V |
| Width | 0.049inch |
Compliance
RoHS : Compliant
Radiation Hardening : No
Images
Mouser
Digikey
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Vishay Vitramon | Unknown | ||
| Vishay Vitramon | Unknown | ||
| Vishay Vitramon | Unknown | ||
| Vishay Vitramon | Unknown | ||
| Vishay Vitramon | Unknown | ||
| Vishay Vitramon | Unknown | ||
| Vishay Vitramon | Unknown | ||
| Vishay Vitramon | Unknown | ||
| Kyocera AVX | Volume Production | ||
| Kyocera AVX | Volume Production |
Authorized Distributors
Associate Distributors
Distributor |
SKU |
Stock |
USD |
1 |
10 |
50 |
100 |
1000 |
10000 |
Buy |
|---|---|---|---|---|---|---|---|---|---|---|
| IBS Electronics |
US: 4,000
|
$ | 0.1168 | |||||||
| Ampacity Systems |
MY: 1,404
|
$ | 0.092 | 0.092 | 0.092 | 0.092 | 0.092 | 0.092 | ||
| VNN Services |
EU: 51
|
$ | ||||||||
| Sourcengine |
US: 4,000
|
$ | ||||||||
