929665-01-08-I - 3M
Conn Unshrouded Header HDR 16 POS 2.54mm Solder ST Top Entry Thru-Hole Box
Technical Details
| China RoHS | Compliant |
| Color | Black |
| Connector Type | Male Pin |
| Contact Gender | Male |
| Contact Mating Length | 5.969mm |
| Contact Plating | Gold |
| Current Rating | 2.5A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Housing Material | PBT |
| Harmonized Tariff Schedule (HTS) Code | 8536.69.40.40 |
| Insulation Resistance | 5GΩ |
| Introduction Date | 1999-01-01 |
| Lead Length | 2.79mm |
| Lifecycle Status | Obsolete |
| Mating Post Length | 5.97mm |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -40°C |
| Mount | Through Hole |
| Number of Pins | 16 |
| Number of Positions | 16 |
| Number of Rows | 2 |
| Packaging | Bulk |
| Pitch | 2.54mm |
| Plating Thickness | 254nm |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Row Spacing | 2.54mm |
| Terminal Pitch | 2.54mm |
| Termination | Solder |
| Voltage Rating | 1.5kV |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
Images
TTI
Authorized Distributors
| Distributor | SKU | Stock | USD | 1 | 10 | 50 | 100 | 1000 | 10000 | Buy |
|---|---|---|---|---|---|---|---|---|---|---|
| TTI |
US: 1372
|
$ | 3.75 | 3.75 | 3.00 | 2.18 | 1.95 | |||
| DigiKey |
DE: 0
|
$ | 3.9571 | 3.5971 | 3.5971 | 3.9571 | 2.2978 | 2.0601 | ||
Non-Authorized Distributors
| Distributor | SKU | Stock | USD | 1 | 10 | 50 | 100 | 1000 | 10000 | Buy |
|---|---|---|---|---|---|---|---|---|---|---|
| Quest |
US: 400
|
$ | 4.00 | 2.50 | 2.20 | 2.00 | 1.65 | 1.65 | ||
| Freelance Electronics |
US: 106
|
$ | 1.61 | 1.61 | 1.21 | 1.12 | 1.12 | 1.12 | ||
| Classic Components |
US: 40
|
$ | ||||||||
