LT6556IUF#TR - Analog Devices / Linear Technology
LT6556 - 750MHz Gain of 1 Triple 2: 1Video Multiplexer
Technical Details
| Case/Package | QFN |
| Height - Seated (Max) | 800µm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.00.60 |
| Input Offset Voltage (Vos) | 18mV |
| Introduction Date | 2005-08-19 |
| Length | 4mm |
| Max Operating Temperature | 85°C |
| Max Supply Current | 13mA |
| Max Supply Voltage | 6V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.25V |
| Nominal Gain Bandwidth Product | 750MHz |
| Number of Channels | 1 |
| Number of Circuits | 3 |
| Number of Terminals | 24 |
| Operating Supply Voltage | 5V |
| REACH SVHC | No |
| RoHS | Non-Compliant |
| Slew Rate | 2100V/µs |
| Temperature Grade | Industrial |
| Terminal Pitch | 500µm |
| Width | 4mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
Images
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Analog Devices | Production | ||
| Analog Devices | Production | ||
| Analog Devices | Production | ||
| Analog Devices | Production | ||
| Analog Devices / Linear Technology | Unknown | ||
| Analog Devices / Linear Technology | Unknown | ||
| Analog Devices / Linear Technology | Unknown |
