ADG1211YCPZ-REEL7 - Analog Devices
Low Capacitance, Low Charge Injection ±15 V/+12 V iCMOS Quad SPST Switches
Technical Details
| -3db Bandwidth | 700MHz |
| Bandwidth | 700MHz |
| Case/Package | LFCSP EP |
| Dual Supply Voltage | 15V |
| Interface | Parallel |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | PRODUCTION |
| Max Dual Supply Voltage | 16.5V |
| Max Operating Temperature | 125°C |
| Max Power Dissipation | 150µW |
| Max Supply Current | 380µA |
| Max Supply Voltage | 16.5V |
| Min Dual Supply Voltage | 4.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 5V |
| Number of Bits | 4 |
| Number of Channels | 4 |
| Number of Circuits | 1 |
| Number of Inputs | 4 |
| Number of Outputs | 4 |
| Number of Pins | 16 |
| Operating Supply Current | 220µA |
| Operating Supply Voltage | 12V |
| Power Dissipation | 150µW |
| Resistance | 190Ω |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Supply Type | Dual, Single |
| Test Frequency | 1MHz |
| Throw Configuration | SPST |
| Turn-Off Delay Time | 115ns |
| Turn-On Delay Time | 130ns |
Compliance
RoHS : Unconfirmed
