ADG1604BRUZ-REEL - Analog Devices
GULL WING Surface Mount Not Qualified ROHS3Compliant Switch IC 70dB 60pF 270pF 1.1Ohm 125pC
Technical Details
| -3db Bandwidth | 19MHz |
| Bandwidth | 19MHz |
| Case/Package | TSSOP |
| Interface | Parallel |
| Lead Free | Contains Lead |
| Lifecycle Status | Production |
| Logic Function | Multiplexer |
| Manufacturer Lifecycle Status | PRODUCTION |
| Max Dual Supply Voltage | 8V |
| Max Operating Temperature | 125°C |
| Max Power Dissipation | 2.8mW |
| Max Supply Voltage | 16V |
| Min Dual Supply Voltage | 3.3V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 3.3V |
| Number of Channels | 4 |
| Number of Circuits | 1 |
| Number of Inputs | 4 |
| Number of Outputs | 1 |
| Number of Pins | 14 |
| Operating Supply Current | 230µA |
| Operating Supply Voltage | 5V |
| Power Dissipation | 2.8mW |
| Resistance | 1.1Ω |
| RoHS | Compliant |
| Supply Type | Dual, Single |
| Turn-Off Delay Time | 95ns |
Compliance
RoHS : Unconfirmed
Images
