ADG1612BCPZ-REEL7 - Analog Devices
1 Ω Typical On Resistance, ±5 V, +12 V, +5 V, and +3.3 V Quad SPST Switches
Technical Details
| -3db Bandwidth | 38MHz |
| Bandwidth | 38MHz |
| Case/Package | VQFN |
| Interface | Parallel |
| Lead Free | Contains Lead |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | PRODUCTION |
| Max Dual Supply Voltage | 8V |
| Max Operating Temperature | 125°C |
| Max Power Dissipation | 5.8mW |
| Max Supply Current | 480µA |
| Max Supply Voltage | 16V |
| Min Dual Supply Voltage | 3.3V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 3.3V |
| Number of Channels | 4 |
| Number of Circuits | 4 |
| Number of Inputs | 4 |
| Number of Outputs | 4 |
| Number of Pins | 16 |
| Packaging | Cut Tape |
| Power Dissipation | 5.8mW |
| REACH SVHC | No |
| Resistance | 1.2Ω |
| RoHS | Compliant |
| Schedule B | 8542390000 |
| Supply Type | Dual, Single |
| Test Frequency | 1MHz |
| Turn-Off Delay Time | 137ns |
| Turn-On Delay Time | 212ns |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
Images
Farnell
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Analog Devices | Production | ||
| Renesas | Obsolete | ||
| Analog Devices | Production | ||
| Analog Devices | Unknown | ||
| Analog Devices | Unknown | ||
| Analog Devices | Obsolete | ||
| Renesas | Obsolete | ||
| Vishay | Production | ||
| Vishay | Production | ||
| Analog Devices | Production |
