ADG201HSKRZ-REEL - Analog Devices
50Ω 4 SPST(SPST)-Normally closed SOIC-16 Analog Switches / Multiplexers ROHS
Technical Details
| Case/Package | R |
| Contact Plating | Tin |
| Dual Supply Voltage | 15V |
| High Level Output Current | 20mA |
| Interface | Parallel |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | PRODUCTION |
| Max Dual Supply Voltage | 16.5V |
| Max Operating Temperature | 125°C |
| Max Power Dissipation | 240mW |
| Max Supply Current | 10mA |
| Max Supply Voltage | 16.5V |
| Min Dual Supply Voltage | 10.8V |
| Min Operating Temperature | -55°C |
| Min Supply Voltage | 10.8V |
| Number of Bits | 4 |
| Number of Channels | 4 |
| Number of Circuits | 4 |
| Number of Inputs | 4 |
| Number of Outputs | 4 |
| Number of Pins | 16 |
| Operating Supply Current | 10mA |
| Packaging | Tape & Reel (TR) |
| Polarity | Non-Inverting |
| Power Dissipation | 240mW |
| Radiation Hardening | No |
| Resistance | 50Ω |
| RoHS | Compliant |
| Supply Type | Dual, Single |
| Throw Configuration | SPST |
| Turn-Off Delay Time | 50ns |
| Turn-On Delay Time | 50ns |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
