ADG426BRSZ-REEL - Analog Devices
SSOP-28-208mil Signal Switches / Encoders & Decoders / Multiplexers ROHS
Technical Details
| Case/Package | SOP |
| Contact Plating | Tin |
| Dual Supply Voltage | 15V |
| High Level Output Current | 20mA |
| Interface | Parallel |
| Lifecycle Status | Production |
| Logic Function | Multiplexer |
| Manufacturer Lifecycle Status | PRODUCTION |
| Max Dual Supply Voltage | 22V |
| Max Operating Temperature | 85°C |
| Max Power Dissipation | 3.1mW |
| Max Supply Voltage | 25V |
| Min Operating Temperature | -40°C |
| Number of Channels | 1 |
| Number of Circuits | 1 |
| Number of Inputs | 16 |
| Number of Outputs | 1 |
| Number of Pins | 28 |
| Operating Supply Current | 100µA |
| Operating Supply Voltage | 12V |
| Packaging | Tape & Reel (TR) |
| Power Dissipation | 3.1mW |
| Radiation Hardening | No |
| Resistance | 80Ω |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Supply Type | Dual, Single |
| Turn-Off Delay Time | 110ns |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
