Technical Details
| Case/Package | DIP |
| Dual Supply Voltage | 12V |
| Height | 4.95mm |
| High Level Output Current | 20mA |
| Interface | Parallel |
| Lead Free | Contains Lead |
| Length | 39.75mm |
| Max Dual Supply Voltage | 16.5V |
| Max Operating Temperature | 125°C |
| Max Power Dissipation | 470mW |
| Max Supply Current | 1.5mA |
| Max Supply Voltage | 16.5V |
| Min Dual Supply Voltage | 10.8V |
| Min Operating Temperature | -55°C |
| Min Supply Voltage | 10.8V |
| Number of Channels | 1 |
| Number of Circuits | 1 |
| Number of Pins | 28 |
| Operating Supply Current | 1.5mA |
| Operating Supply Voltage | 15V |
| Packaging | Bulk |
| Power Dissipation | 26mW |
| Propagation Delay | 300ns |
| Resistance | 700Ω |
| RoHS | Compliant |
| Turn-Off Delay Time | 450ns |
| Turn-On Delay Time | 450ns |
| Width | 14.73mm |
Compliance
RoHS : Unconfirmed
Images
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Intersil | Production | ||
| Intersil | Obsolete | ||
| Analog Devices | Unknown | ||
| Intersil | Obsolete | ||
| Renesas | Production | ||
| Analog Devices | Unknown | ||
| Analog Devices | Unknown | ||
| Vishay | Obsolete | ||
| Analog Devices | Unknown | ||
| Analog Devices | Production |
Authorized Distributors
| Distributor | SKU | Stock | USD | 1 | 10 | 50 | 100 | 1000 | 10000 | Buy |
|---|---|---|---|---|---|---|---|---|---|---|
| Rochester Electronics |
US: 17
|
$ | 12.39 | 11.77 | 10.53 | 9.91 | ||||
