ADG612YRUZ - Analog Devices
Analog Switch Quad Single Pole Single Throw ±5.5 Volt 5.5 Volt 16-Pin TSSOP
Technical Details
| -3db Bandwidth | 680MHz |
| Bandwidth | 680MHz |
| Case/Package | TSSOP |
| Drain to Source Resistance | 85Ω |
| Dual Supply Voltage | 5V |
| Height | 1.05mm |
| High Level Output Current | 10mA |
| Interface | Parallel |
| Length | 5mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | PRODUCTION |
| Max Dual Supply Voltage | 5.5V |
| Max Operating Temperature | 125°C |
| Max Power Dissipation | 10µW |
| Max Supply Current | 1µA |
| Max Supply Voltage | 5.5V |
| Min Dual Supply Voltage | 2.7V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.7V |
| Nominal Supply Current | 1µA |
| Number of Bits | 4 |
| Number of Channels | 4 |
| Number of Circuits | 4 |
| Number of Inputs | 4 |
| Number of Outputs | 4 |
| Number of Pins | 16 |
| Operating Supply Current | 1nA |
| Packaging | Bulk |
| Polarity | Non-Inverting |
| Power Dissipation | 10µW |
| Radiation Hardening | No |
| REACH SVHC | No |
| Resistance | 115Ω |
| RoHS | Compliant |
| Schedule B | 8542390000 |
| Supply Type | Dual, Single |
| Throw Configuration | SPST |
| Turn-Off Delay Time | 40ns |
| Turn-On Delay Time | 65ns |
| Width | 4.4mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
