ADG726BCPZ - Analog Devices
MULTIPLEXER, ANALOGUE, LFCSP-EP; Available until stocks are exhausted Alternative available
Technical Details
| -3db Bandwidth | 34MHz |
| Bandwidth | 34MHz |
| Case/Package | LFCSP EP |
| Contact Plating | Tin |
| Dual Supply Voltage | 2.5V |
| Height | 830µm |
| High Level Output Current | 30mA |
| Interface | Parallel |
| Length | 7mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | PRODUCTION |
| Max Operating Temperature | 85°C |
| Max Power Dissipation | 100µW |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 1.8V |
| Number of Channels | 16 |
| Number of Circuits | 2 |
| Number of Inputs | 32 |
| Number of Outputs | 2 |
| Number of Pins | 48 |
| Operating Supply Voltage | 5V |
| Power Dissipation | 100µW |
| REACH SVHC | No |
| Resistance | 5.5Ω |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Turn-Off Delay Time | 16ns |
| Width | 7mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
