ADM803LAKSZ-REEL7 - Analog Devices
IC SUPERVISOR 1 CHANNEL SC70-3 Supervisor Open Drain or Open Collector 1 Channel SC-70-3
Technical Details
| Case/Package | SC |
| Height | 1.1mm |
| Length | 2mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | PRODUCTION |
| Max Operating Temperature | 125°C |
| Max Reset Threshold Voltage | 4.7V |
| Max Supply Current | 60µA |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -40°C |
| Min Reset Threshold Voltage | 4.56V |
| Min Supply Voltage | 1V |
| Mount | Surface Mount |
| Nominal Supply Current | 60µA |
| Number of Elements | 1 |
| Number of Monitored Inputs | 1 |
| Number of Outputs | 1 |
| Number of Pins | 3 |
| Number of Voltages Monitored | 1 |
| Operating Supply Current | 35µA |
| Output Current | 20mA |
| Overvoltage Threshold | 4.7V |
| Radiation Hardening | No |
| REACH SVHC | No |
| Reset | Active Low |
| Reset Delay Time | 840ms |
| Reset Timeout | 240ms |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000, 8542390000|8542390000|8542390000, 8542390000|8542390000|8542390000|8542390000 |
| Threshold Voltage | 4.63V |
| Type | Simple Reset/Power-On Reset |
| Undervoltage Threshold | 4.56V |
| Watchdog Timer | No |
| Width | 1.25mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
