Analog Devices - ADP2503ACPZ-4.2-R7

ADP2503ACPZ-4.2-R7 - Analog Devices

IC REG BCK BST 4.2V 10LFCSP "Buck-Boost Switching Regulator IC Positive Fixed 4.2V 1 Output 600mA 10-VFDFN Exposed...

 Datasheets

Technical Details

Case/Package LFCSP EP
Contact Plating Tin
Lead Free Contains Lead
Lifecycle Status Production
Manufacturer Lifecycle Status PRODUCTION
Max Input Voltage 5.5V
Max Operating Temperature 125°C
Max Output Current 600mA
Max Output Voltage 5.5V
Min Input Voltage 2.3V
Min Operating Temperature -40°C
Min Output Voltage 2.8V
Mount Surface Mount
Nominal Supply Current 50µA
Number of Outputs 1
Number of Pins 10
Operating Supply Current 50µA
Operating Supply Voltage 5.5V
Output Configuration Positive
Output Current 600mA
Output Type Fixed
Output Voltage 4.2V
Packaging Digi-Reel®
RoHS Compliant
Switching Frequency 2.5MHz
Synchronous Rectifier Yes
Topology Buck-Boost
