ADP3333ARMZ-2.5-R7 - Analog Devices
IC REG LINEAR 2.5V 300MA 8MSOP Linear Voltage Regulator IC Positive Fixed 1 Output 300mA 8-MSOP
Technical Details
| Accuracy | 0.8% |
| Case/Package | MSOP |
| Contact Plating | Tin |
| Dropout Voltage | 140mV |
| Height | 850µm |
| Lead Free | Contains Lead |
| Length | 3mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | PRODUCTION |
| Max Input Voltage | 12V |
| Max Operating Temperature | 85°C |
| Max Output Current | 300mA |
| Max Supply Current | 5.5mA |
| Min Input Voltage | 2.6V |
| Min Operating Temperature | -40°C |
| Number of Outputs | 1 |
| Number of Pins | 8 |
| Number of Regulators | 1 |
| Operating Supply Current | 5.5mA |
| Output Current | 300mA |
| Output Type | Fixed |
| Output Voltage | 2.5V |
| Polarity | Positive |
| Power Supply Rejection Ratio (PSRR) | 60dB |
| Quiescent Current | 70µA |
| REACH SVHC | No |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000, 8542390000|8542390000|8542390000, 8542390000|8542390000|8542390000|8542390000 |
| Width | 3mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
Images
Farnell
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Analog Devices | Unknown | ||
| Analog Devices | Unknown | ||
| Analog Devices | Unknown | ||
| Analog Devices | Unknown | ||
| Analog Devices | Production | ||
| Analog Devices | Unknown | ||
| Analog Devices | Production | ||
| Analog Devices | Production | ||
| Texas Instruments | Unknown | ||
| Analog Devices | Unknown |
