ADP8870ACBZ-R7 - Analog Devices
Charge Pump Parallel Backlight Driver with Image Content PWM Input
Technical Details
| Dimming | PWM |
| Height | 645µm |
| Lead Free | Contains Lead |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | PRODUCTION |
| Max Input Voltage | 5.5V |
| Max Junction Temperature (Tj) | 125°C |
| Max Operating Temperature | 105°C |
| Max Output Current | 240mA |
| Max Supply Voltage | 5.5V |
| Min Input Voltage | 2.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.5V |
| Mount | Surface Mount |
| Nominal Supply Current | 1.5µA |
| Number of Outputs | 7 |
| Number of Pins | 20 |
| Output Current | 30mA |
| Output Current per Channel | 60mA |
| Output Voltage | 4.7V |
| Packaging | Digi-Reel® |
| RoHS | Compliant |
| Switching Frequency | 1MHz |
| Topology | Charge Pump |
| Width | 2.15mm |
Compliance
RoHS : Unconfirmed
Images
Analog Devices
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Analog Devices | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Unknown | ||
| Texas Instruments | Production | ||
| Analog Devices | Production | ||
| Texas Instruments | Unknown | ||
| Texas Instruments | Unknown | ||
| Texas Instruments | NRND | ||
| Texas Instruments | Production |
