LT3478IFE#PBF - Analog Devices
LED Driver 6 Segment 6100uA Supply Current 16-Pin TSSOP EP Tube
Technical Details
| Case/Package | TSSOP |
| Frequency | 2.25MHz |
| Height | 1.1mm |
| High Level Output Current | 40µA |
| Lead Free | Lead Free |
| Lifecycle Status | Production |
| Low Level Output Current | 40µA |
| Manufacturer Lifecycle Status | PRODUCTION |
| Max Input Voltage | 36V |
| Max Junction Temperature (Tj) | 125°C |
| Max Operating Temperature | 125°C |
| Max Supply Voltage | 36V |
| Min Input Voltage | 2.8V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.4V |
| Nominal Supply Current | 6.1mA |
| Number of Outputs | 1 |
| Number of Pins | 16 |
| Output Current | 4.5A |
| Output Voltage | 41V |
| Radiation Hardening | No |
| REACH SVHC | No |
| RoHS | Compliant |
| Switching Frequency | 2.25MHz |
| Topology | Boost, Buck, Buck-Boost |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
Images
Farnell
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| NXP Semiconductors | Production | ||
| Allegro MicroSystems | Obsolete | ||
| Allegro MicroSystems | Unknown | ||
| Analog Devices | Production | ||
| Analog Devices | Production | ||
| Analog Devices | Production | ||
| Analog Devices | Production | ||
| Microchip | Production | ||
| Texas Instruments | Unknown | ||
| Analog Devices | Production |
