LT3593ES6#TRMPBF - Analog Devices
LT3593 - 1MHz White LED Driver with Output Disconnect and One Pin Current Programming
Technical Details
| Case/Package | TSOT |
| Frequency | 1.15MHz |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | PRODUCTION |
| Max Input Voltage | 5.5V |
| Max Operating Temperature | 85°C |
| Max Supply Voltage | 5.5V |
| Min Input Voltage | 2.7V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.7V |
| Nominal Supply Current | 10µA |
| Number of Outputs | 1 |
| Number of Pins | 6 |
| Number of Segments | 10 |
| Output Current | 20mA |
| Output Voltage | 45V |
| Packaging | Cut Tape |
| Radiation Hardening | No |
| REACH SVHC | No |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Switching Frequency | 1MHz |
| Topology | Boost |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
Images
