LT3599IUH#PBF - Analog Devices
LED DRVR 40Segment 3.3V/5V/9V/12V/15V/18V/24V Automotive 32-Pin QFN EP
Technical Details
| Case/Package | QFN |
| Frequency | 2.1MHz |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | PRODUCTION |
| Max Input Voltage | 30V |
| Max Operating Temperature | 125°C |
| Max Supply Voltage | 30V |
| Min Input Voltage | 3V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 3V |
| Number of Outputs | 4 |
| Number of Pins | 32 |
| Number of Segments | 40 |
| Output Current | 120mA |
| Output Voltage | 44V |
| REACH SVHC | No |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Switching Frequency | 2.06MHz |
| Topology | Boost, SEPIC |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
Images
Farnell
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Analog Devices | Obsolete | ||
| Analog Devices | Obsolete | ||
| Analog Devices | Obsolete | ||
| Analog Devices | Unknown | ||
| Analog Devices | Production | ||
| Analog Devices | Production | ||
| Analog Devices | Obsolete | ||
| onsemi | Obsolete | ||
| Analog Devices | Unknown | ||
| Analog Devices | Obsolete |
