LT3756EUD-1#PBF - Analog Devices
LED Driver 18 Segment 1700uA Supply Current 16-Pin QFN EP Tube
Technical Details
| Case/Package | QFN |
| Frequency | 1MHz |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | PRODUCTION |
| Max Input Voltage | 100V |
| Max Operating Temperature | 125°C |
| Max Supply Voltage | 100V |
| Min Input Voltage | 6V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 6V |
| Number of Outputs | 1 |
| Number of Pins | 16 |
| Number of Segments | 18 |
| Output Voltage | 100V |
| REACH SVHC | No |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Switching Frequency | 1MHz |
| Topology | Boost, Buck, Buck-Boost, SEPIC |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
Images
Newark
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Analog Devices | Obsolete | ||
| Analog Devices | Unknown | ||
| Analog Devices | EOL | ||
| Analog Devices | Obsolete | ||
| Analog Devices | Obsolete | ||
| Texas Instruments | Production | ||
| Analog Devices | Unknown | ||
| Analog Devices | Obsolete | ||
| Texas Instruments | Unknown | ||
| Texas Instruments | Unknown |
