LTC3534EDHC#TRPBF - Analog Devices
Switching Regulator, Voltage-mode, 1150kHz Switching Freq-Max, CMOS, PDSO16
Technical Details
| Case/Package | DFN |
| Efficiency | 94% |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | PRODUCTION |
| Max Input Voltage | 7V |
| Max Operating Temperature | 85°C |
| Max Output Voltage | 7V |
| Min Input Voltage | 2.4V |
| Min Operating Temperature | -40°C |
| Number of Channels | 1 |
| Number of Outputs | 1 |
| Number of Pins | 16 |
| Output Current | 500mA |
| Output Type | Adjustable |
| Output Voltage | 7V |
| Packaging | Tape and Reel |
| RoHS | Compliant |
| Switching Frequency | 1MHz |
| Synchronous Rectifier | Yes |
| Topology | Buck-Boost |
Compliance
RoHS : Unconfirmed
Images
Analog Devices
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Analog Devices | Production | ||
| Analog Devices / Linear Technology | Unknown | ||
| Analog Devices | Production | ||
| Analog Devices | Production | ||
| Analog Devices | Production | ||
| Analog Devices | Production | ||
| Analog Devices | Production | ||
| Analog Devices | Production | ||
| Analog Devices | Production | ||
| Analog Devices | Production |
