LTC3615EFE#PBF - Analog Devices
Switching Regulator, Current-mode, 7.5A, 2700kHz Switching Freq-Max, CMOS, PDSO24
Technical Details
| Case/Package | TSSOP |
| Current - Output 1 | 3A |
| Current - Output 2 | 3A |
| Efficiency | 94% |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | PRODUCTION |
| Max Input Voltage | 5.5V |
| Max Operating Temperature | 125°C |
| Min Input Voltage | 2.25V |
| Min Operating Temperature | -40°C |
| Number of Channels | 1 |
| Number of Outputs | 2 |
| Number of Pins | 24 |
| Output Current | 3A |
| Output Type | Adjustable |
| Output Voltage | 5.5V |
| Packaging | Cut Tape |
| REACH SVHC | No |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Switching Frequency | 4MHz |
| Synchronous Rectifier | Yes |
| Voltage - Output 1 | 5.5V |
| Voltage - Output 2 | 5.5V |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
Images
Analog Devices
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Analog Devices | Production | ||
| Analog Devices | Production | ||
| Analog Devices | Production | ||
| Texas Instruments | Production | ||
| Analog Devices | Production | ||
| Analog Devices | Production | ||
| Analog Devices | Production | ||
| Analog Devices | Production | ||
| Texas Instruments | Unknown | ||
| Analog Devices | Production |
