LTC3646IDE#PBF - Analog Devices
IC REG BUCK ADJ 1A 14DFN Buck Switching Regulator IC Positive Adjustable 2V 1 Output 1A 14-WFDFN Exposed Pad
Technical Details
| Case/Package | DFN |
| Lead Free | Lead Free |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | PRODUCTION |
| Max Input Voltage | 40V |
| Max Operating Temperature | 125°C |
| Max Output Voltage | 30V |
| Min Input Voltage | 4V |
| Min Operating Temperature | -40°C |
| Min Output Voltage | 2V |
| Number of Outputs | 1 |
| Number of Pins | 14 |
| Output Current | 1A |
| Output Type | Adjustable |
| Output Voltage | 30V |
| Packaging | Cut Tape |
| REACH SVHC | No |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Switching Frequency | 3MHz |
| Synchronous Rectifier | Yes |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
Images
Newark
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Richtek | Production | ||
| Richtek | Obsolete | ||
| Analog Devices | Obsolete | ||
| Richtek | Obsolete | ||
| Richtek | Production | ||
| Richtek | Obsolete | ||
| Monolithic Power Systems | Production | ||
| Richtek | Production | ||
| Richtek | Obsolete | ||
| Richtek | Production |
