LTC3809EDD-1#PBF - Analog Devices
IC REG CTRLR BUCK 10DFN Buck Regulator Positive Output Step-Down DC-DC Controller IC 10-DFN (3x3)
Technical Details
| Case/Package | DFN |
| Duty Cycle | 100% |
| Frequency | 750kHz |
| Lead Free | Lead Free |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | PRODUCTION |
| Max Frequency | 600kHz |
| Max Input Voltage | 9.8V |
| Max Operating Temperature | 85°C |
| Max Output Current | 1A |
| Max Output Voltage | 9.8V |
| Max Supply Voltage | 9.8V |
| Min Operating Temperature | -40°C |
| Min Output Voltage | 600mV |
| Min Supply Voltage | 2.75V |
| Mount | Surface Mount |
| Number of Channels | 1 |
| Number of Outputs | 1 |
| Number of Pins | 10 |
| Output Current | 1A |
| Output Voltage | 9.8V |
| REACH SVHC | No |
| RoHS | Compliant |
| Termination | SMD/SMT |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
