LTM4612IV#PBF - Analog Devices
Conv DC-DC Single Non-Inv/Inv/Step Up/Step Down 5V to 36V uModule Automotive 133-Pin LGA
Technical Details
| Case/Package | LGA |
| Frequency | 850kHz |
| Height | 2.794mm |
| Length | 14.986mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | PRODUCTION |
| Max Input Voltage | 36V |
| Max Operating Temperature | 125°C |
| Max Output Current | 5A |
| Max Output Voltage | 15V |
| Min Input Voltage | 5V |
| Min Operating Temperature | -40°C |
| Min Output Voltage | 3.3V |
| Number of Channels | 1 |
| Number of Outputs | 1 |
| Number of Pins | 133 |
| Operating Supply Current | 4.5mA |
| Output Current | 5A |
| Output Type | Adjustable |
| Output Voltage | 15V |
| Packaging | Cut Tape |
| REACH SVHC | No |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000, 8542390000|8542390000|8542390000, 8542390000|8542390000|8542390000|8542390000 |
| Switching Frequency | 1.3MHz |
| Topology | Buck |
| Voltage - Output 1 | 15V |
| Width | 14.986mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
