MAT14ARZ - Analog Devices
Bipolar (BJT) Array Transistor, NPN, 40 V, 30 mA, 300, SOIC ; RoHS Compliant: Yes
Technical Details
| Case/Package | SOIC |
| Collector Base Voltage (VCBO) | 40V |
| Collector Emitter Breakdown Voltage | 40V |
| Collector Emitter Saturation Voltage | 30mV |
| Collector Emitter Voltage (VCEO) | 40V |
| Frequency | 300MHz |
| Gain Bandwidth Product | 300MHz |
| Height | 1.75mm |
| hFE Min | 300 |
| Lead Free | Contains Lead |
| Length | 8.75mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | PRODUCTION |
| Max Collector Current | 30mA |
| Max Frequency | 1kHz |
| Max Junction Temperature (Tj) | 150°C |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Elements | 4 |
| Number of Pins | 14 |
| Polarity | NPN |
| Radiation Hardening | No |
| REACH SVHC | No |
| RoHS | Compliant |
| Schedule B | 8541210080, 8541210080|8541210080|8541210080|8541210080|8541210080 |
| Transition Frequency | 300MHz |
| Width | 4mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
