MAX5069BAUE+ - Analog Devices
High-Frequency, Current-Mode PWM Controller with Accurate Oscillator and Dual FET Drivers
Technical Details
| Case/Package | TSSOP |
| Clock Sync | Yes |
| Duty Cycle | 100% |
| Evaluation Kit | Yes |
| Features | UVLO |
| Frequency | 2.5MHz |
| Lead Free | Lead Free |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | PRODUCTION |
| Max Duty Cycle | 100% |
| Max Frequency | 1.25MHz |
| Max Operating Temperature | 125°C |
| Max Supply Voltage | 24V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 10.8V |
| Mount | Surface Mount |
| Nominal Input Voltage | 23.6V |
| Number of Output Phases | 1 |
| Number of Outputs | 1 |
| Number of Pins | 16 |
| Operating Supply Voltage | 72V |
| Output Current | 1A |
| Radiation Hardening | No |
| REACH SVHC | No |
| RoHS | Compliant |
| Switching Frequency | 1.25MHz |
| Synchronous Rectifier | No |
| Topology | Push-Pull |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
