MAX6315US30D4+T - Analog Devices
Processor Supervisor 3V 1V to 5.5V - 4-Pin(3+Tab) SOT-143 T/R
Technical Details
| Case/Package | TO-253-4 |
| Height | 1.22mm |
| Lead Free | Contains Lead, Lead Free |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | PRODUCTION |
| Max Operating Temperature | 125°C |
| Max Power Dissipation | 320mW |
| Max Reset Threshold Voltage | 3.05V |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -40°C |
| Min Reset Threshold Voltage | 2.95V |
| Min Supply Voltage | 1V |
| Mount | Surface Mount |
| Number of Outputs | 1 |
| Number of Pins | 4 |
| Number of Voltages Monitored | 1 |
| Operating Supply Current | 5µA |
| Output Current | 20mA |
| Overvoltage Threshold | 3.05V |
| Packaging | Tape & Reel (TR) |
| Radiation Hardening | No |
| Reset | Active Low |
| Reset Timeout | 1.57s |
| RoHS | Compliant |
| Threshold Voltage | 3V |
| Type | Simple Reset/Power-On Reset |
| Undervoltage Threshold | 2.95V |
| Watchdog Timer | No |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
