MAX8543EEE+ - Analog Devices
-40¡Í~+85¡Í@(TA) Step-down 1.2MHz 3V~13.2V Yes 1 Step-down type QSOP-16 DC-DC Controllers ROHS
Technical Details
| Case/Package | QSOP |
| Clock Sync | Yes |
| Evaluation Kit | Yes |
| Fall Time | 100ns |
| Lead Free | Lead Free |
| Lifecycle Status | Production |
| Max Frequency | 1.2MHz |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Output Phases | 1 |
| Number of Outputs | 1 |
| Number of Pins | 16 |
| Operating Supply Current | 3mA |
| Operating Supply Voltage | 13.2V |
| Output Configuration | Positive |
| Output Current | 25A |
| Output Voltage | 11.88V |
| Radiation Hardening | No |
| Rise Time | 100ns |
| RoHS | Compliant |
| Switching Frequency | 1.2MHz |
| Synchronous Rectifier | Yes |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
