Technical Details
| Accuracy | 1% |
| Case/Package | SOT-23-5 |
| Dropout Voltage | 165mV |
| Height | 1.45mm |
| Lifecycle Status | Production |
| Max Input Voltage | 6.5V |
| Max Junction Temperature (Tj) | 150°C |
| Max Operating Temperature | 85°C |
| Max Power Dissipation | 571mW |
| Max Supply Voltage | 6.5V |
| Min Input Voltage | 2.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 3.7V |
| Mount | Surface Mount |
| Noise | 170 |
| Number of Outputs | 1 |
| Number of Pins | 5 |
| Number of Regulators | 1 |
| Output Current | 150mA |
| Output Type | Fixed |
| Output Voltage | 2.7V |
| Polarity | Positive |
| Radiation Hardening | No |
| RoHS | Compliant |
| Watchdog Timer | No |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
