Technical Details
| Case/Package | 100 |
| Color | Red |
| Connector Type | Lug, Solder |
| Country of Origin | UK |
| Forward Current | 20mA |
| Height | 3mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.40.20.00 |
| Illumination Color | Red |
| Introduction Date | 2005-04-28 |
| Length | 44.75mm |
| Lens Color | Diffused, Red |
| Lens Style | Diffused |
| Life (Hours) | 100000hours |
| Lifecycle Status | Production |
| Luminous Intensity | 50mcd |
| Material | Brass |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Panel |
| Number of Circuits | 1 |
| Number of LEDs | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Operating Supply Voltage | 12V |
| Packaging | Bulk |
| Ratings | IP67 |
| REACH SVHC | No |
| Reverse Voltage | 5V |
| RoHS | Compliant |
| Shape | Round |
| Termination | Solder |
| Viewing Angle | 100° |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
