0ZCJ0010FF2E - Bel Fuse
Resettable Fuse, PPTC, 1206 (3216 Metric), 0ZCJ Series, 60 VDC, 100 mA, 250 mA, 1 s
Technical Details
| Approvals | TUV, UL |
| Case/Package | 1206 |
| Case Code (Imperial) | 1206 |
| Case Code (Metric) | 3216 |
| China RoHS | Compliant |
| Contact Plating | Tin |
| Current Rating | 10A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 850µm |
| Hold Current | 100mA |
| Harmonized Tariff Schedule (HTS) Code | 8533.40.80.70 |
| Introduction Date | 2013-04-06 |
| Lead Free | Lead Free |
| Length | 3.5mm |
| Lifecycle Status | Production |
| Max Current Rating | 10A |
| Max Operating Temperature | 85°C |
| Maximum Resistance 1 Hour (R1max) | 15Ω |
| Max Voltage Rating (DC) | 60V |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Terminals | 2 |
| Packaging | Tape & Reel (TR) |
| Power Dissipation | 400mW |
| REACH SVHC | Yes |
| Resistance | 1.6Ω |
| RoHS | Compliant |
| Schedule B | 8533290000|8533290000|8533290000|8533290000|8533290000|8533290000|8533290000|8533290000|8533290000|8533290000|8533290000|8533290000|8533290000|8533290000|8533290000|8533290000|8533290000|8533290000|8533290000|8533290000|8533290000|8533290000|8533290000|85 |
| Time to Trip | 1s |
| Trip Current | 250mA |
| Voltage Rating | 60V |
| Width | 1.8mm |
| Working Voltage | 60V |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
