0ZCM0003FF2G - Bel Fuse
Resettable Ptc Fuse, Smd, 0603 Size, 30Ma, 30V Rohs Compliant: Yes
Technical Details
| Case/Package | 0603 |
| China RoHS | Compliant |
| Current Rating | 40A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 750µm |
| Hold Current | 30mA |
| Harmonized Tariff Schedule (HTS) Code | 8533.40.80.70 |
| Introduction Date | 2019-09-26 |
| Length | 1.8mm |
| Lifecycle Status | Production |
| Max Operating Temperature | 85°C |
| Maximum Resistance 1 Hour (R1max) | 50Ω |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Terminals | 2 |
| REACH SVHC | Yes |
| Resistance | 6Ω |
| RoHS | Compliant |
| Time to Trip | 1s |
| Trip Current | 90mA |
| Voltage Rating | 30V |
| Width | 1mm |
| Working Voltage | 30V |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
