Technical Details
| China RoHS | Compliant |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 3mm |
| Hold Current | 2.5A |
| Harmonized Tariff Schedule (HTS) Code | 8533.40.80.70 |
| Introduction Date | 2002-11-13 |
| Lifecycle Status | Production |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Terminals | 2 |
| Operating Supply Voltage | 15V |
| Power Dissipation | 1.9W |
| REACH SVHC | Yes |
| Resistance | 85mΩ |
| RoHS | Compliant |
| Trip Current | 5A |
| Width | 6.71mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
