SMBJ24A - Brightking
ESD Suppressor / TVS Diodes VRWM=24V VBR(min)=26.7V VC=38.9V@IPP=15.5A SMB
Technical Details
| Breakdown Voltage | 28.1V |
| Clamping Voltage | 38.9V |
| Max Breakdown Voltage | 29.5V |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 5W |
| Min Breakdown Voltage | 26.7V |
| Min Operating Temperature | -65°C |
| Number of Elements | 1 |
| Number of Terminals | 2 |
| Peak Pulse Power | 600W |
| Polarity | Unidirectional |
| Reverse Standoff Voltage | 24V |
| RoHS | Compliant |
Compliance
RoHS : Unconfirmed
