KM1202A08QE - C&K Components
Switch Push Button ON Mom SPDT Round Button 0.25A 125VAC 125VDC Momentary Contact Thru-Hole PC Pins
Technical Details
| Actuator Length | 7.62mm |
| Actuator Material | Nylon |
| Color | Natural |
| Contact Current Rating | 250mA |
| Contact Material | Copper |
| Contact Plating | Silver |
| Contact Resistance | 30mΩ |
| Contact Voltage Rating (AC) | 125V |
| Country of Origin | Vietnam |
| Current Rating | 250mA |
| Depth | 23.32mm |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 10kcycles |
| Flammability Rating | UL94 V-2 |
| Height | 9.78mm |
| Housing Material | Nylon |
| Harmonized Tariff Schedule (HTS) Code | 8536.50.90.31 |
| Insulation Resistance | 10GΩ |
| Introduction Date | 2006-04-01 |
| Lead Free | Lead Free |
| Length | 13.72mm |
| Life (Cycles) | 10kcycles |
| Lifecycle Status | Production |
| Max Current Rating | 250mA |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (AC) | 125V |
| Max Voltage Rating (DC) | 125V |
| Min Operating Temperature | -30°C |
| Mount | Through Hole |
| Orientation | Right Angle |
| Packaging | Bulk |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Sealable | EPOXY TERMINAL SEALED |
| Switch Function | On-Mom |
| Terminal Material | Copper |
| Termination | PC Pins |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 125V |
| Voltage Rating (DC) | 125V |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
