PTS636SKG25SMTRLFS - C&K Components
Switch Tactile OFF Mom SPST Rectangular Button Gull Wing 0.05A 12VDC 2.45N SMD T/R
Technical Details
| Color | Red |
| Contact Current Rating | 50mA |
| Contact Resistance | 100mΩ |
| Electrical Life | 100kcycles |
| Height | 1.9mm |
| Insulation Resistance | 100MΩ |
| Length | 6.1mm |
| Life (Cycles) | 100kcycles |
| Lifecycle Status | Production |
| Max Current Rating | 50mA |
| Max Operating Temperature | 90°C |
| Max Voltage Rating (DC) | 12V |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Positions | 1 |
| Operating Force | 2.94N |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Schedule B | 8536509065 |
| Sealable | IP40 |
| Throw Configuration | SPST |
| Voltage Rating (DC) | 12V |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
