PTS830GM140SMTRLFS - C&K Components
Switch Tactile N.O. SPST Round Button Gull Wing 0.05A 12VDC 500000Cycles 1.57N SMD T/R
Technical Details
| Contact Current Rating | 50mA |
| Contact Plating | Silver |
| Contact Resistance | 100mΩ |
| Electrical Life | 500kcycles |
| Height | 1mm |
| Illumination Type | Non-Illuminated |
| Insulation Resistance | 100MΩ |
| Length | 3.05mm |
| Life (Cycles) | 500kcycles |
| Lifecycle Status | Production |
| Max Current Rating | 50mA |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (DC) | 12V |
| Mechanical Life | 500kcycles |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Positions | 1 |
| Operating Force | 2.06N |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Sealable | IP40 |
| Switch Function | Off-Mom |
| Switch Travel | 150µm |
| Termination | Gull Wing |
| Throw Configuration | SPST |
| Voltage Rating (DC) | 12V |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
Images
TME
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| C&K Components | Production | ||
| C&K Components | Production | ||
| C&K Components | Production | ||
| E-Switch | Production | ||
| C&K Components | Obsolete | ||
| C&K Components | Production | ||
| C&K Components | Production | ||
| C&K Components | Production | ||
| C&K Components | Production | ||
| C&K Components | Production |
