Technical Details
| Approvals | UL, VDE |
| Body Plating | Chrome |
| Color | Blue |
| Current Rating | 9mA |
| Forward Current | 17mA |
| Forward Voltage | 24V |
| Height | 2mm |
| Hole Diameter | 14.5mm |
| Lens Color | Blue |
| Life (Hours) | 100hours |
| Luminous Intensity | 500mcd |
| Material | Brass |
| Max Operating Temperature | 50°C |
| Min Operating Temperature | -20°C |
| Mount | Panel |
| Operating Supply Voltage | 24V |
| Outside Diameter | 16mm |
| Peak Wavelength | 475nm |
| RoHS | Compliant |
| Thread Size | M14 |
| Voltage Rating | 24V |
| Voltage Rating (DC) | 24V |
| Wavelength | 475nm |
Compliance
RoHS : Unconfirmed
