742C043331JP - CTS Components
Res Thick Film Array 330 Ohm 5% 0.125W(1/8W) ±200ppm/C ISOL 4-Pin 0606(2 X 0603) Concave SMD Medical T/R
Technical Details
| Case/Package | 0606 |
| Circuit Type | Isolated |
| Composition | Thick Film |
| Contact Plating | Tin |
| Height | 525µm |
| Length | 1.6mm |
| Lifecycle Status | Production |
| Max Operating Temperature | 125°C |
| Military Standard | Not |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Circuits | 2 |
| Number of Elements | 1 |
| Number of Pins | 4 |
| Number of Resistors | 2 |
| Number of Terminals | 4 |
| Packaging | Tape & Reel |
| Power Dissipation | 126mW |
| Power Per Element | 62.5mW |
| Power Rating | 126mW |
| REACH SVHC | Yes |
| Resistance | 330Ω |
| RoHS | Compliant |
| Schedule B | 8533100057 |
| Temperature Coefficient | 200ppm/°C |
| Terminal Pitch | 800µm |
| Termination | Concave |
| Tolerance | 5% |
| Voltage Rating | 50V |
| Width | 1.6mm |
| Working Voltage | 50V |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
