PDQ2-D24-D12-S - CUI Inc
PDQ2 Series 2 W 24 V Input ±12 V Dual Output Isolated DC/DC Converter - SIP-8
Technical Details
| Case/Package | SIP |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Efficiency | 81% |
| Features | OCP, SCP |
| Height | 11.176mm |
| Height - Seated (Max) | 11.6mm |
| Introduction Date | 2018-06-13 |
| Isolation Voltage | 1500Vrms |
| Lead Free | Lead Free |
| Length | 21.8mm |
| Lifecycle Status | Production |
| Max Input Voltage | 36V |
| Max Operating Temperature | 85°C |
| Max Output Current | 83mA |
| Max Output Power | 2W |
| Max Output Voltage | 12.18V |
| Max Power Dissipation | 2W |
| Min Input Voltage | 18V |
| Min Operating Temperature | -40°C |
| Min Output Voltage | 11.82V |
| Mount | Through Hole |
| Nominal Input Voltage | 24V |
| Nominal Output Voltage | 12V |
| Number of Circuits | 1 |
| Number of Outputs | 2 |
| Number of Terminals | 7 |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Schedule B | 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Temperature Grade | Industrial |
| Terminal Pitch | 2.5mm |
| Voltage - Output 1 | 12V |
| Voltage - Output 2 | -12V |
| Width | 9.2mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
Images
Onlinecomponents.com
Authorized Distributors
Non-Authorized Distributors
| Distributor | SKU | Stock | USD | 1 | 10 | 50 | 100 | 1000 | 10000 | Buy |
|---|---|---|---|---|---|---|---|---|---|---|
| Fly-Wing Technology |
HK: 1952
|
$ | 10.3422 | 9.7568 | 9.7568 | 9.2045 | 8.192 | 8.192 | ||
| Augswan |
CN: 1825
|
$ | 11.4208 | 11.1924 | 11.1924 | 10.8498 | 10.5071 | 10.0503 | ||
