Technical Details
| Approvals | CE, EN, IEC, UL |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Efficiency | 93% |
| Height - Seated (Max) | 28.7mm |
| Introduction Date | 2021-03-03 |
| Length | 61.8mm |
| Lifecycle Status | Production |
| Max Input Voltage | 75V |
| Max Operating Temperature | 85°C |
| Max Output Current | 5A |
| Max Output Power | 75W |
| Max Output Voltage | 15.75V |
| Min Input Voltage | 18V |
| Min Operating Temperature | -40°C |
| Min Output Voltage | 13.5V |
| Nominal Input Voltage | 48V |
| Nominal Output Voltage | 15V |
| Number of Circuits | 1 |
| Number of Outputs | 1 |
| Number of Terminals | 8 |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Width | 40.2mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
